Feature
- Support 4 HDMI inputs, 4 HDMI outputs.
- Support HDMI 1.4 standard, HDCP1.4 standard.
- HDMI input supports simultaneous audio and video input; it has 4 audio output interfaces, which can be connected to external mixers, processors, active speakers and other equipment for sound reinforcement.
- The maximum input and output resolution can reach 3840×2160@30Hz, which is compatible with any resolution below the maximum resolution, and the output resolution is consistent with the input resolution.
- DC 12V power supply, the maximum power consumption is 20W.
Product Detail
| Model | TS-9104UHM |
| Digital video input | 4×HDMI Digital video input |
| Output interface | 4×HDMI Digital video output, 4×analog audio output port |
| Control interface | 1×NETWORK、1×RS 232、1×IR IN、1×USB UPDATE |
| HDMI | HDMI1.4 |
| HDCP | HDCP1.4 |
| HDMI maximum bandwidth | 10.2Gbps |
| Maximum transmission distance | 10m（3840×2160(30Hz)）；15 m（1080P(60Hz)） |
| Environment temperature | -10℃—+45℃ |
| Ambient humidity | 10%-80% |
| Power supply | DC 12V |
| Power consumption | 20W |
| Dimension（L*W*H） | 484*298*45mm |
| Weight | 3.5Kg |
