Feature
- Adopt WiFi transmission technology and strict digital protection to ensure meeting privacy, and avoid eavesdropping and malicious interference.
- Non-gooseneck microphone, array pickup method, good directivity.
- With microphone status indicator.
- With OLED screen, it can display microphone on/off, ID setting, power, signal strength, and SSID display.
- Adopt uncompressed audio transmission technology, support up to 48K sampling rate, and provide perfect sound quality with a bandwidth of 80Hz-16KHz.
- Support PC software microphone control function, support conference management, personnel management, and system management.
- Support voice control function. The sensitivity of voice control can be adjusted, the microphone can be turned on intelligently and the closing time can be set.
- The chairman has a priority to turn off all speaking delegate microphones.
- Support the 5-band EQ adjustment function of the microphone. It can adjust different sound effects according to the voice characteristics of the speaker until the perfect effect is achieved.
- Built-in 18650 lithium battery. Support 12 hours of continuous speech or 16 hours of static standby.
- Support turning off all units with one key on the controller.


Product Detail
Model | TS-0212/TS-0212A |
Microphone type | ECM array wireless microphone |
Microphone core quantity | 13 |
Frequency response | 80Hz~16KHz |
Microphone input impedance | 200Ω |
Sensitivity | -30dB (0dB=1V/pa, @1kHz) |
SNR | >80dB(A) |
Crosstalk | >70dB |
Dynamic range | >80dB |
Max SPL | 112dB (THD≤0.5%, @1KHz) |
THD | <0.1% |
Max power consumption | 1.5W |
Directivity | Corridor |
Standard | IEC-60914 |
Power supply | 18650 lithium battery/2 batteries |
Charging method | Connect the charging box through Type-C |
Colour | Graphite gray |
Sign-in function | Key sign in |
Display screen | OLED screen/0.96 inches |
Wireless frequency range | 5.15~5.85GHz |
Battery capacity | 4800mAh |
Working hours in speech mode | 12 hours |
Working hours in mixed mode | 14 hours |
Dimension | 250×90×50mm (L×W×H) |
Installation method | Desktop |
