Feature:
- 48KHz sampling rate, clear and bright sound, better than CD sound quality, internal DSP audio processing technology, no low-frequency impact sound.
- Adopt an advanced chip structure and unique processing algorithm, the start-up time of the microphone is 5 seconds only.
- Intelligent failure detection, including AP failure, controller communication failure, and low signal strength, etc.
- Support charging the unit via the Typle-C port with an intelligent status indicator.
- Support SSID and password functions.
- Support language switching of Chinese and English through the PC software.
- Support the functions of speech countdown and speech timekeeping.
- The delegate unit can apply for speaking with the approval of the chairman.
- Voice control function can turn on the microphone intelligently, and can set the voice sensitivity and shutdown time of the microphone via the software.
- Support sign-in function, support setting and starting the sigh-in through PC software.
- Support voting function, five-key voting and three-key voting, flexible and convenient.
- Adopt 128-bit AES encryption technology, support WPA/WPA2 wireless security technology, prevent eavesdropping and unauthorized access, provide higher confidentiality of the conference system.
- Wireless transmission technology, convenient and time-saving wiring.
- The chairman has a priority function to turn off all delegate microphones that are speaking.
- Built-in lithium battery supports 14 hours of continuous speech.
- Support offline program upgrade.
- 4.3-inch full-view IPS capacitive touch screen.
- The power switch is at the bottom of the microphone.


Product Detail
Model | TS-W103D/TS-W103DA |
Microphone type | Cardioid directional electret |
Frequency response | 80Hz~16KHz |
Input impedance | 1KΩ |
Sensitivity | -34±2dB (0dB=1V/Pa at 1kHz) |
Maximum SPL | 100dB(THD>3%) |
SNR | >80dB(A) |
Crosstalk | >70dB |
Dynamic range | >80dB |
THD | <0.1% |
Maximum power consumption | 3W |
Standard | IEC60914 |
Power supply | 18650 lithium battery |
Charging method | Connect to the charging box through the Type-C interface |
Color | Graphite gray |
Sign in | Touch screen sign in |
Screen | IPS screen |
Size | 149*145*61(mm) |
Installation | Desktop |
Wireless frequency range | 5.15~5.85GHz |
Battery capacity | 10400mAh |
Microphone pole | 220mm |
Weight | 1Kg |
Speech mode working hour | 13h |
Mixed mode working hour | 14h |
