Feature
- Unique patented technology, designed with anti-RF interference hose, completely eliminates the sizzling noise.
- Unique microphone head design, even without cotton cover, it can completely eliminate the low frequency “pop”
- Professional large cardioid condenser microphone core, extremely high sensitivity and voice clarity, red and green annular indicator light.
- Red indicator light means MIC is speaking; green indicator light means it is applying to speak.
- Support squealing suppression function, when microphone is turned on, built-in speaker will be off.
- Designed with built-in speaker and earphone jack, earphone volume is adjustable.
- The unit cascading uses a professional 8-pin aviation connector with a metal fixing nut, ensuring it would not loosen or fall off.
- The unit comes with a 1.8mwire; the wire is shielded by full aluminum foil + waterline, which greatly reduces the interference of strong electromagnetic waves on the wire and eliminates the sizzling noise.
- The address code of each unit is freely adjustable to facilitate construction.
- Passive unit, conference controller power supply, 24V DC, safety range.
- The number of spokesmen of the chairman unit is not limited.
- Chairman unit has the priority to control the entire conference process.
- The connection position of the chairman unit is not limited, and it can be connected in series at any position of the line.
- Hand-in-hand connection, easy for installation and maintenance.



Product Detail
Model | TS-0621 |
Microphone Type | Cardioid directional electret |
Frequency Response | 80Hz~16KHz |
MIC Input Impedance | 1KΩ |
Sensitivity | -34±2dB(0dB=1V/Pa,at 1kHz) |
Max SPL | 100dB(THD>3%) |
SNR | >80dB |
Crosstalk | >70dB |
Dynamic Range | >80dB |
THD | <0.1% |
Max Consumption | 2W |
Earphone Load | 8-32Ω |
Earphone Volume | Max 40mW |
Earphone Jack | 3.5mmMono jack |
Standard | IEC60914 |
Connector | 1.8m Aviation 8 core |
Power Supply Mode | DC24V |
Color | Silver |
Weight | 0.9kg |
Microphone Length | 409mm |
Dimension(mm) | 225(L)×131(W)×48(H) |
Mounting | Desktop |
