Feature:
- 48KHZ sampling rate, clear and bright sound, better than CD sound quality, built-in DSP audio processor and no low frequency “pop” noise.
- Support functions of speech timekeeping and speech countdown.
- The delegate unit can apply for speaking with approval of the chairman unit.
- Support internal feedback suppression function.
- Support voice control function, and adjustable voice control sensitivity.
- Support 5-bandEQ adjustment function, adjust sound effects according to the characteristics of different speakers to achieve the perfect effect.
- The chairman has the priority function to turn off all delegate units that are speaking.
- Designed with a 3-inch TFT color touch screen, simple and user-friendly operation.
- 100M network transmission, hand-in-hand cascade, long-distance transmission with good sound quality.
- Support IC card sign-in function.
- Support voting and rating functions.
- Support electronic nameplate function,display the participant name on the full-view LCD screen, and the display information can be updated through the PC conveniently.
- Support ID editing function,andsupport multiple language receiving channels: 15 + 1(default), 31 + 1 and 63 + 1(optional).
- Support language switching of Chinese and English, and one-key switching.
- Sign-in and voting functions will be realized through touch button instead of physical button.
- Support conference service function, ask for the service with one key.
- Support background SMS notification, support fire alarm linkage prompt.
- Support real-time display of sign-and-voting process, and synchronous display in the background.



Product Detail
Model | TS-0203/TS-0203A |
Microphone type | Cardioid directional electret microphone |
Frequency response | 80Hz~16KHz |
Input impedance | 1KΩ |
Sensitivity | -34±2dB(0dB=1V/Pa,at 1KHz) |
Maximum SPL | 100dB (THD>3%) |
SNR | >80dB(A) |
Crosstalk | >70dB |
Dynamic range | >80dB |
THD | <0.1% |
Maximum power consumption | 5.5W |
Headphone load | >16Ω |
Headphone volume | 40mW maximum |
Headphone jack | 3.5mm mono jack |
Standard | IEC60914 |
Connector | 1.8m 6-pin aviation connector |
Power supply | Controller power supply DC 36V |
Color | Black |
Voting | 5-key voting, 3-key voting |
Simultaneous interpretation | 16(default), 32, 64 channels |
Sign-in | Key sign-in, IC card sign-in |
IC card | With contact IC card |
Screen | 4.3-inch color screen |
Electronic nameplate | 5.5-inch green electronic nameplate |
Wight | 1.17kg |
Microphone pole | 409mm |
Size | 218×135×63mm |
Installation method | Desktop |
