Feature:
- 1U cabinet, small in size and light in weight.
- The latest class-D amplifier design has low distortion and high efficiency.
- Switched power supply has high efficiency and can effectively suppress power harmonics.
- Intelligent peak clipper controls the power module and speaker system to work in a safe range.
- Standard XLR+TRS1/4 “composite input interface, simple interface design is more convenient for different users. There are two balanced input interfaces and two balanced cascade output interfaces.
- Soft starters can prevent absorbing large currents into the power grid when starting up and interfering with other electrical devices.
- Intelligent forced heat dissipation design, low fan noise, high dissipation efficiency, etc.
- Suitable for different places, stereo mode or bridge mode is optional.
- With over-voltage protection, under voltage protection, over temperature voltage limit, over temperature shutdown, over current voltage limit, over current shutdown, DC protection, output short circuit protection, temperature control fan, amplifier frequency synchronization and other functions.


Product Detail
Model | D-200 |
Output power | 8Ω 120Wx2, 4Ω 200Wx2 |
Bridge 8Ω | 400W |
Conversion rate | 50V/us |
Input sensitivity | 1Vrms |
Input impedance | 10K Ω unbalanced、20KΩ balanced |
Frequency response(@1W power) | 20Hz-20KHz/+0/-1dB |
THD+N(@1/8 power) | ≤0.05% |
Resolution(@1KHz) | ≥75dB |
Damping coefficient(1KHz) | ≥200@ 8 ohms |
SNR | >95dB |
Input voltage | ~230V(50/60Hz) |
Maximum power consumption | 550W |
Size | 483x300x44mm |
Weight | 4.4Kg |
