- The integrated input and output design can be freely configured as input terminal, output terminal, or KVM terminal.
- Support 1920*1080P@60fps, 1920*1080P@30fps high-definition video signal input and backward compatibility, when used as an output node, support 1920*1080P@60fps, 1920*1080P@30fps high-definition output and backward compatibility,and transmit multiple streams at the same time.
- Support 4-channel 1080P@60fps or 8-channel 1080P@30fps H264/H265 decoding display, support screening, scaling, overlaying, splitting, and roaming.
- Support real-time preview of the input signal through the client, and the signal status is under control.
- Station logo: Without adding external devices, it supports adding text or picture to the input source as the logo; the font, font size, color and background color of the logo can be customized; the logo size can be changed as needed.
- Subtitles: Without adding external devices, subtitles (such as welcome messages) can be displayed on the splicing screen. The font size, color, and position can be customized, and dynamic scrolling subtitles are supported.
- Local HD base map: without adding external devices, it supports the display wall base map function; you can load local pictures and can set the base map function on and off on the software.
- With 3.5mm analog audio interface and HDM digital audio interface, it supports the transmission of original PCM audio without coding compression;
- Support KVM function, capture screen and send screen graphically (non-text), send screen to any monitor or large screen, support KVM cross-screen roaming, support virtual mouse control to optimize KVM operation experience, support cross-platform operation, including Windows, Linux, Mac and other system platforms.
- KVM supports OSD menu visual management, the number of preview videos on a single page can be adjusted as needed, the maximum number of previews on a single page can reach 8, and information prompts and confirmations are provided meanwhile.
- Support KVM role permission management, control KVM signal management permission through the server permission management function.
- Support access to fingerprint sensor to realize KVM fingerprint identification login, and support to cooperate with USB camera to realize KVM face recognition login function, and establish a fast, reliable and safe access channel.
- Built-in self-developed video splicing synchronization algorithm, no splicing processor is required, it can be directly connected to LED sending card, LCD, DLP and other splicing screens, and the picture is synced without
- Built-in input synchronization function supports 4 input nodes for synchronous acquisition and synchronous encoding of a 4K signal source and transmits to 4 output nodes for synchronous decoding and synchronous display, the whole 4K signal picture is clear and smooth, without tearing, realizing 1:1 wall display of 4K signal source.
|Processing capability||When used as an input node, it supports 1920*1080P@60fps, 1920*1080P@30fps high-definition video signal input and is backward compatible; when used as an output node, it supports 1920*1080P@60fps, 1920*1080P@30fps high-definition output and is backward compatible. Support 8-channel 1920*1080@30fps codec.|
|Codec capability||Support H.264/H.265 video encoding, PCM audio lossless transmission|
|Video port||1*HDMI IN (support audio), 1*HDMI OUT (support audio), 1*VGA OUT|
|Audio port||1*3.5mm stereo input, 1*3.5mm stereo output, input sensitivity: 775mV|
|USB port||2*USB2.0 (KVM interface), 1*USB3.0 (support video input)|
|Network port||1*RJ45, 10/100/1000Base-T, support POE|
|Serial port||1*RS-485, 1*RS-232|
|Infrared port||1*IR learning window, 4*IR OUT|
|I/O port||3*I/O port|
|Weak relay port||2*RELAY port|
|Reset button||1*pinhole RESET button|
|Mode switch||1*input and output mode switch|
|Display screen||2.23-inch OLED display with 128*32 pixels|
|Power supply||DC 12V/POE|
|Max power consumption||12W|
|Ambient temperature||-10°C~45°C (working state); -15°C~45°C (non-working state)|
|Ambient humidity||5%~90% (working state), no condensation|
