Feature:

  • Short microphone pole design, long-distance pickup.
  • Adopt uncompressed audio transmission technology, 48K sampling rate, 80Hz-16KHz bandwidth perfect sound quality.
  • Adopt 100M network transmission and single-line access to the ring network to improve the reliability of system operation.
  • Adopt standard TCP/IP communication protocol and support ping packet function.
  • Designed with a 4.1-inch circular full-color touch screen.
  • Support63+1 simultaneous interpretation channels, all the speeches of the chairman and delegate units are listened to in channel 0, and channels 1 to 63 are the channels for listening to the interpreter machine.
  • With 15mm headphones interfaces, supports listening to the sound of any channel for 63+1 channel.
  • Support PC software for microphone control, support voice control function.
  • The chairman has the priority to turn off the speaking delegate unit.
  • Built-in independent web server, support four language switching, adjustment of microphone ID and microphone sensitivity.
  • Support the function of speech timekeeping and speech countdown, the delegate unit supports the function of requesting a speech.

Product Detail

Model TS-0318C/ TS-0318CA
Microphone type Electret condenser microphone
Microphone directivity Cardioid
Frequency response 80Hz~16KHz
Input impedance 1KΩ
Sensitivity -40±1dB (0dB=1V/Pa, at 1KHz)
Max SPL 120dB(THD>3%)
SNR >80dB(A)
Crosstalk >70dB
Dynamic range >80dB
THD <0.1%
Max power consumption 4W
Power supply Conference host power supply
Color Fine sand graphite gray
Sign-in function Key sign in
Installation method Desktop
Microphone pole 240mm
Dimension (L×W×H) 100.9×130×54.3mm(base)
Weight 1.2KG
