Feature:

  • 48KHZ sampling rate, clear and bright sound, better than CD sound quality, built-in DSP audio processor, and no low frequency “pop” noise.
  • Support functions of speech timekeeping and speech countdown.
  • The delegate unit can apply for speaking with approval of the chairman.
  • Support internal feedback suppression function.
  • Support voice-control function, and adjustable voice control sensitivity.
  • Support 5-bandEQ adjustment function, adjust sound effects according to the characteristics of different speakers to achieve the perfect effect.
  • The chairman has the priority function to turn off all delegate units that are speaking.
  • Designed with a 3-inch TFT color touch screen, simple and user-friendly operation.
  • 100M network transmission, hand-in-hand cascade, long-distance transmission with good sound quality.
  • Equipped with a 3.5mm outlet, for recording and connecting the headphones.
  • Equipped with a 3.5mm inlet, for connecting the headphones.
  • Support voting and rating function; the chairman unit can initiate voting and sign-in; data statistics can be fulfilled without a
  • Support ID editing function,andsupport multiple language receiving channels: 15 + 1(default), 31 + 1 and 63 + 1(optional).
  • Support conference service function, participants can send their demands to the background.
  • Sign-in and voting functions will be realized through touch button instead of a physical button.
  • Support real-time display of sign-in and voting process, and synchronous display in the background.

Product Detail

ModelTS-0205
Microphone typeCardioid directional electret
Frequency response80Hz~16KHz
Input impedance1KΩ
Sensitivity-46 dBV/Pa
Maximum SPL125dB(THD>3%)
SNR>80dB(A)
Crosstalk>70dB
Dynamic range>80dB
THD<0.1%
Maximum power consumption5W
Headphone load>16Ω
Headphone volume4OmW maximum
Headphone jack 3.5mm mono jack
StandardIEC60914
ConnectorWith 1.8m 6-pin aviation connector
Power supplyController power supply DC36V
ColorGray
Voting5-key voting, 3-key voting
Simultaneous interpretation16(default), 32, 64 channels
Sign-inTouch button sign-in
Screen4.3-inch capacitive color screen
Microphone pole409mm
InstallationDesktop
Wight1kg
Size206×174.2×65.5mm
