Feature:
- 48KHz sampling rate, clear and bright sound, better than CD sound quality; internal DSP audio processing technology, making no low-frequency impact sound.
- Adopting advanced chip structure and unique processing algorithm, the microphone is turned on in 5 seconds only.
- With an intelligent fault detection function, it prompts the user of AP faults, controller communication faults, low signal strength, etc.
- SupportChinese and English interface language switching, which can be set uniformly through PC software.
- Support the button SSID setting function, ensuring that the wrong AP will not be connected when extending the system.
- Support the functions of speech countdown and speech time
- With voice control function, it can turn on the microphones intelligently and can adjust the voice sensitivity and set the shutdown time of the microphone via PC software.
- With 5-band EQ adjustment function (via PC software), it can adjust the sound effects of all microphones to achieve the perfect effects.
- Support sign-in function: set and start the sigh-via PC software.
- Adopt128-bit AES encryption technology, support WPA/WPA2 wireless security technology, prevent eavesdropping and unauthorized access and provide higher confidentiality of the conference system.
- Adopt wireless transmission technology, making wiring convenient and time-saving.
- The chairman has a priority function to turn off all delegate microphones that are speaking.
- Built-in lithium battery can support15hours of continuous speech.
- Built-in antenna can greatly improve wifi network transmission efficiency.


Product Detail
Model | TS-W102 |
Microphone type | Cardioid directional electret microphone |
Frequency response | 70Hz~12KHz |
Sensitivity | -36±1.5dB |
Maximum SPL | 100dB(THD>3%) |
SNR | >80dB(A) |
Crosstalk | >70dB |
Dynamic range | >80dB |
THD | <0.1% |
Maximum power consumption | 1W |
Standard | IEC60914 |
Power supply | 18650 lithium battery |
Charging method | Connect to the charging box via the TYPE-C interface |
Color | Blue |
Sign in | Touch button sign in |
Screen | OLED screen |
Size (L×W×H) | 120*104*43mm |
Installation method | Desktop |
Wireless frequency range | 5.15GHz~5.85GHz |
Battery capacity | 4800mAh |
Weight | 0.6Kg |
Speech mode working hour | 15H |
Mixed mode working hour | 16H |
Microphone pole | 380mm(black) |
