Feature

  • The capacitive touch buttons can effectively eliminate the button tapping noise and ensure a good venue environment.
  • Uncompressed audio transmission technology, 48K sampling rate, 80Hz-16KHz bandwidth perfect sound quality.
  • Adopt100M network transmission, adopt network cable hand-in-hand connection, convenient for wiring.
  • Adopt standard TCP/IP communication protocol, support ping packet function.
  • Adopt a 5-inch full-color touch screen.
  • Support63+1 simultaneous interpretation channels, support dual-channel listening function, listen to different interpreter channels at the same time.
  • support PC software microphone control and voice control function.
  • The chairman unit has the priority to turn off the speaking delegate
  • With a built-in independent web server, support four language switching, support adjustment of microphone ID number, microphone sensitivity, microphone EQ and other parameters.
  • Support the function of speech timekeeping and speech countdown.
  • Support feedback suppression function and voice control function and the voice control sensitivity is adjustable
  • Support 5-band EQ adjustment function, adjust sound effects according to the voice characteristics of different speakers until the perfect effect is achieved.
  • Support the sign-in function, stop unit sign-in and control unit sign-in through the PC software.
  • Support the voting function, there are multiple voting modes, and the content of the options can be customized and sent to the unit for display.
  • Support web page firmware upgrade function.
  • Support the IP address sniffing function; the ID number, IP address, MAC address and other parameters of the unknown unit can be found through the PC tool.

Product Detail

Model TS-0309D// TS-0309DA
Microphone type Electret condenser microphone
Microphone directivity Cardioid
Frequency response 80Hz~16kHz
Microphone input impedance 1KΩ
Sensitivity -40±1dB (0dB=1V/Pa,at 1KHz)
Maximum SPL 120dB(THD>3%)
SNR >80dB(A)
Crosstalk >70dB
Dynamic range >80dB
THD <0.3%
Maximum power consumption 3.5W
Power supply Conference server power supply
Color Fine sand graphite grey
Sign-in method button to sign in
Dimension 145.7*133.6*45(mm) (L*W*H)(without Microphone pole)
Microphone pole 240mm
Installation method Desktop
Weight 1kg
