Feature:
- Industrial modeling aluminum panel, durable design, removable and washable dust-proof mesh, and cooling vents.
- Soft starters can prevent absorbing large currents into the power grid when starting up and interfering with other electrical devices.
- Intelligent forced heat dissipation design, low fan noise, high dissipation efficiency, etc.
- 2-channel amplifier with three options of input sensitivity supports a wide range ofsignal source input.
- Comprehensive and reliable security protection measures and working status indicators (short circuit, overload, DC and overheat protection, transformer overheat protection).
- Built-in intelligent clipping limiter controls the power module and the speaker system to work in a safe range.
- Standard XLR+TRS1/4″ composite multi-function input interface, simple interface design is more convenient for different user
- High-quality transformer, low resistance and large capacity electrolytic filter make large dynamic work smooth.
- Suitable for different places, stereo mode or bridge modes are optional.
- With grounded input pin and suspension control.


Product Detail
Model | TS-500PI |
Output power (20-20KHz/THD≤1%)
stereo/parallel 8Ω X 2 |
500W×2 |
Output power (20-20KHz/THD≤1%)
stereo/parallel 4Ω X 2 |
730W×2 |
Bridge 8Ω | 1460W |
Input | XLR, TRS interface |
Voltage gain (@1KHz) | 36.2dB |
Input sensitivity | 0.775V/1V/1.44V |
Input impedance | 10KΩ unbalanced, 20KΩ balanced |
Frequency response(@ 1W power) | 20-20KHz/+0/-2dB |
THD+N(@1/8 power) | ≤0.05% |
SNR (A-weighted) | ≥95dB |
Damping coefficient (@ 1KHz) | ≥200@ 8Ω |
Resolution (@1KHz) | ≥80dB |
Protection method | Over current protection, DC protection, short circuit protection |
Indicator | Power, protection, distortion |
Cooling method | Fan cooling |
Power supply | ~220V, 50Hz |
Maximum power consumption | 2200W |
Size | 483×464×88mm |
Weight | 15.8Kg |
