Feature

  • Digital transmission link, connected to the cascade port of the conference server for power supply through the network port to six-pin aviation cable, uncompressed audio transmission technology, 48K sampling rate, 80Hz-16KHz bandwidth perfect sound quality.
  • The capacitive touch buttons can effectively eliminate the button tapping noise and ensure a good venue environment.
  • support PC software microphone control and voice control function.
  • The chairman unit has the priority to turn off the speaking delegate
  • Support TCP/IP protocol cluster, support ICMP, HTTP, UDP, TCP, IGMP and other protocols.
  • Support the PING packet function.
  • With an independent web control page, support adjusting parameters such as microphone ID number, microphone sensitivity, and microphone EQ.
  • Support feedback suppression function and voice control function and the voice control sensitivity is adjustable.
  • Support5-band EQ adjustment function, adjust sound effects according to voice characteristics of different speakers until the perfect effect is achieved.
  • Support the sign-in function, and stop unit sign-in, control unit sign-in and other functions through PC software
  • Support web page firmware upgrade function.
  • Support the IP address sniffing function; the ID number, IP address, MAC address and other parameters of the unknown unit can be found through the PC tool.

Product Detail

ModelTS-0308/TS-0308A
Microphone typeElectret condenser microphone
Microphone directivityCardioid
Frequency response80Hz~16KHz
Microphone input impedance1KΩ
Sensitivity-34±2dB(0dB=1V/Pa,at1KHz)
Maximum SPL120dB(THD>3%)
SNR>80dB(A)
Crosstalk>70dB
Dynamic range>80dB
THD<0.3%
Maximum power consumption2W
Network port2, cascaded network ports
Power supplyConference server power supply
ColorGray
Dimension113×100×36mm (L×W×H) (excluding the length of the microphone pole)
Microphone pole380mm black
Installation methodDesktop
Weight0.8kg
