Feature

  • Digital transmission link, connected to conference controller cascade port for power supply through network port to six-core aviation cable; uncompressed audio transmission technology, 48K sampling rate, 80Hz-16kHz bandwidth perfect sound quality.
  • The use of capacitive touch buttons can effectively eliminate the noise of button knocking and ensure a good venue environment.
  • Built-in high-fidelity speaker with volume adjustment and howling suppression function. When the microphone is turned on, the built-in speaker will be automatically turned off.
  • The chairman unit has a priority function to shut down all delegate microphones that are speaking. When the scheduled speech function is turned on, the chairman unit is not restricted
  • With a 3.5mm stereo output socket, it can be used for recording and connecting headphones.
  • With 5-band EQ adjustment function, the sound effect can be adjusted according to the sound characteristics of different speakers to achieve the perfect effect.
  • Support voice control function, and adjustable voice control sensitivity.
  • With an independent web control page, it supports the adjustment of microphone ID number, microphone sensitivity, microphone EQ and other parameters.

Product Detail

Model TS-0302/ TS-0302A
Microphone type Cardioid Electret Microphone
Frequency response 80Hz-16kHz
Input impedance 680Ω
Sensitivity -41±1.5dBV/Pa
Maximum SPL 120dB
SNR >80dB(A)
Dynamic range >80dB
THD <0.3%
Power consumption 4W
Headphone load 16-32Ω
Headphone jack 3.5mm
Network port 2 cascade network ports
Power supply Powered by conference controller
Color Graphite gray
Sign in function Touch button sign in
Installation method Desktop installation
Weight 0.56kg
Microphone pole 409mm black
Dimension (L×W×H) 178.6×114×58.2mm (without microphone pole)
