Feature:

  • Embedded fully digital touch control design, elegant and compact appearance, user-friendly operation.
  • Digital transmission link, connected to the conference controller cascade port for power supply through network cable; uncompressed audio transmission technology, 48K sampling rate, 80Hz-16KHz bandwidth perfect sound quality.
  • Capacitive touch keys are adopted to ensure no key-tapping sound and a good environment in the venue.
  • The unit supports microphone control and voice control functions by PC software.
  • The chairman unit has the priority to turn off the delegate unit.
  • With standard TCP/IP protocol, support ICMP, HTTP, UDP, TCP, IGMP and other protocols.
  •  Support PING packet function.
  • The unit has an independent web control page, which supports adjusting parameters such as microphone ID number and microphone sensitivity.
  • Support the functions of speech timekeeping and speech countdown; the delegate unit can apply for speaking.
  • The unit has voice control function, and the voice control sensitivity is adjustable.
  • Support sign-in function. You can also disable and control the unit check-in, and other functions through the PC software.
  • Support firmware upgrade function on the web page.
  • Support the IP address sniffing function. And the ID number, IP address, MAC address and other parameters of the unknown unit can be found through the PC tool.

Product Detail

Microphone type Cardioid Electret
Microphone directivity Cardioid
Frequency response 80Hz~16kHz
Microphone input impedance 630Ω
Sensitivity -41±1.5dB (0dB=1V/Pa,at 1KHz)
Maximum SPL 120dB
SNR >80dB(A)
Crosstalk >70dB
Dynamic range >80dB
THD <0.1%
MAX power consumption 2W
Power supply Conference controller
Color Graphite gray
Sign in Key
Dimension (LxWxH) 108*77*129mm
Microphone rod 409mm black
Installation method Embedded
Weight 0.30kg
Desktop opening size 65×54mm
